Curl Femoral Iso-Lateral | Lever Machine - Compact Series

The Fitness Tech Curl Femoral Iso-Lateral Compact Series lever machine is designed to develop the hamstrings through a guided, powerful, and fully controlled movement. Thanks to its lever system with plate loading, it allows working each leg independently, promoting a balanced development of the posterior thigh muscles and correcting possible imbalances between both sides of the body.

Its design with torso support and knee positioning allows for more effective isolation of the femoral muscles, reducing lumbar involvement and maintaining stable execution throughout the entire range of motion. This machine offers specific training for the posterior chain, providing constant tension, stability, and safety even during intensive strength sessions.

Kneeling position for total hamstring isolation

With the knees supported on the padded platform and the torso fixed on the upper support, the hip is completely stabilized during flexion, eliminating lumbar involvement and concentrating all effort on the hamstrings: biceps femoris, semitendinosus, and semimembranosus. The iso-lateral system works each leg independently, improving strength and muscular balance between both sides. Built on a Q235 steel tube structure measuring 50 × 80 × 2.5 mm with galvanized anti-corrosion coating, it withstands intensive use in commercial gyms.

Main features

• Iso-lateral lever system: allows working each leg independently to improve muscular balance and hamstring activation.
• Plate loading up to 300 kg: enables progressive adjustment of training intensity according to the user’s level.
• Ergonomic torso support: provides stability during exercise and helps maintain proper body alignment.
• Padded ankle rollers: offer comfort and stability during knee flexion.
• Galvanized Q235 steel structure: 50 × 80 × 2.5 mm tube with anti-corrosion treatment for maximum stability.
• Stainless steel loading sleeves: compatible with Ø50 mm Olympic plates.
• High-density padding: ensures comfort and durability even under frequent use.

Technical specifications

• Dimensions: 192 × 112 × 146 cm
• Weight: 119 kg
• Maximum plate load: 300 kg (150 kg per sleeve)
• Maximum user weight: 180 kg
• Structure: Q235 steel with galvanized anti-corrosion coating
• Main tube: 50 × 80 × 2.5 mm
• Loading sleeves: 2 · stainless steel · Ø50 Olympic
• Plate storage supports: 2 · stainless steel · Ø50 Olympic
• Grips: vulcanized rubber handles
• Upholstery: high-density foam with leather-like finish
• Finish: electrostatic powder coating
• Certifications: CE and EN ISO 20957
